Juniper Networks PTX10003-80C

Network equipment reference

Juniper Networks PTX10003-80C

Reference : PTX10003-80C

OPTINOC preserves this reference for technical research. The equipment is not offered for sale, and an optical-module association is displayed only when it is supported by an official manufacturer source reviewed by our team.

Request a module verification

Technical specifications

Product
Juniper Networks PTX10003
Features
Protection per Firewall, flux d'air avant to l'rear, 3 plateaux de fans, support layers 3 VPN (L3VPN), provisionnement Zero-touch (ZTP), Routing and pontage integrateds (IRB), protection DDoS
Throughput: 8 Tbps
Performances de transmission: 5.3 Bpps
Disque Dur
2 x 200GB SSD
CPU
Processor Intel Broadwell with 12 coeurs
RAM
64 Gb SDRAM
Ports
- 80 x 10Gb Ethernet / 40Gb Ethernet / 100Gb Ethernet / 200Gb Ethernet / 400Gb Ethernet  QSFP28 - 1 x port de management SFP / SFP +1 x  1000Based-T - RJ-45 - 2 x port console - 1 x  USB 2.0
Standards compliance
ETSI, CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, ICES-003 Class A, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE, RoHS 6/6, REACH, EN 60825-1, VCCI Class A, EN 55022 Class A, FCC CFR47 Part 15 A, CNS 13438 Class A, EN 300386, SPRING, KCC KN22 Class A, CAN/CSA-C22.2 No. 60950-1, ETSI EN 300019, ETSI EN 300019-2-1, ETSI EN 300019-2-2, ETSI EN 300019-2-3, ETSI EN 300019-2-4
Included software
Junos OS
chassis type
Rack-mountable - 3U
