Juniper Networks EX9253

Technical specifications

Product

Juniper Networks EX9253

performance

- Switching capacity de fond de panier ( Stack ) : 2.4 Tbps /Slots - Rate de transfert de data : 2.4 Tbps - Throughput: 4.8 Tbps

Capacity

- Routes IPv4: 256000 - Routes IPv6: 256000 - Entries ARP: 512000 - Entries multicast (IPv4): 256000 - Entries multicast (IPv6): 256000 - Files d'attente hardware QoS per port: 8 - Interfaces virtuelles (VLAN): 32000 - policies: 16000

MAC address table size

1 millions d'entries

Data link protocol

Ethernet, Fast Ethernet, Gigabit Ethernet, HDLC, Frame Relay, PPP, MLPPP, MLFR

Routing protocol

OSPF, RIP, BGP-4, IS-IS, RIP-2, BGP, IGMPv2, IGMP, VRRP, OSPFv2, PIM-SM, IGMPv3, MSDP, Static routing IPv4, ECMP, MPLS, Bidirectional Forwarding detection (BFD)

Algorithme de chiffrement

MD5, AES

Protocoles VoIP

SDP

Ports

- 24 x 100Gbit LAN QSFP28/QSFP+ - 144 x 10 Gigabit Ethernet / 10 Gigabit Ethernet SFP+ - 40 x 40 Gigabit Ethernet - 1 x console AUX - 1 x series management - 1 x RJ-45 management - 1 x USB Type A

Power Over Ethernet (PoE)

- PoE+ - Budget PoE : 740W

Processor

1.6 GHz

RAM

32 GB

Disque Dur

SSD 100 GB

Flash memory

100 GB

Remote management protocol

SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, SSH-2, CLI

Standards compliance

IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1ab (LLDP), IEEE 802.1ak

Included software

JUNOS

Expansion slots

3 (total) / 3 (free) x Logement for extension

Power supply

6 alimentations, 4 fans, Routing Engines redondants; Basculement progressif du Routing (GRES)

Power consumption

350 Watt

chassis type

3U
