Network equipment reference

Juniper Networks - DPC-R-4XGE-XFP

Reference : DPC-R-4XGE-XFP

OPTINOC preserves this reference for technical research. The equipment is not offered for sale, and an optical-module association is displayed only when it is supported by an official manufacturer source reviewed by our team.

Request a module verification

Technical specifications

Product: Juniper Networks - DPC-R-4XGE-XFP
Type de produit: expansion module - enfichable hot
Features: firewall protection, support MPLS, weighted faire la queue Round Robin (WRR), filtrage per adresse MAC, support IPv6, weighted support aléatoire detection early (WRED), Spanning Tree Protocol (STP), le support virtuel Route Redundancy Protocol (VRRP), la Quality of Service ( QoS), MPLS VPN, detection de Transfert bidirectionnel (BFD), support IPv4, le tunnel GRE
RAM: 48 GB
Data link protocol: SONET/SDH
Throughput de ligne: OC-48/STM-16
Protocole de liaison: 10 Gigabit Ethernet
Rate de transfert des data: 10.31 Gbps
Remote management protocol: SNMP
Type de câblage: Ethernet 1000Based-TX, Ethernet 100Based-TX, Ethernet 10GBASE-T
performance: - Bande passante : 1600 Gbps per Slots
Ports: - 4 x 10Gb Ethernet - XFP
Compliance standards: certified FFC class A, EN 61000-3-2, VCCI class A ITE, EN 61000-3-3, EN 55022 class A, UL 60950, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, AS/NZ 3548 Class A, EN 61000-4-5, EN 61000-4-11, EN 60950-1, EN 60825-1, BSMI Class A, EN 60825-2, EMI
Standards compliance: IEEE 802.1Q, IEEE 802.3ad (LACP)
Capacity: QoS data queues: 512000
Connecteurs d'extension: - 2 (total) / 2 (free) x connecteur d'extension
Compatibilité: Juniper MX-series MX960
system d'exploitation requis: JUNOS
Power supply: Consommation : 310 Watt
