Network equipment reference

Cisco TelePresence SX10

Reference : CTS-SX10-K9

OPTINOC preserves this reference for technical research. The equipment is not offered for sale, and an optical-module association is displayed only when it is supported by an official manufacturer source reviewed by our team.

Request a module verification

Technical specifications

output video: - Type : Carte CODEC - rack-montable - Affichages graphiques pris en charge : VGA (640x480), XGA (1024x768), SVGA (800x600), HDTV (1920x1080), 1280x720, 1280x768, 1024x576, 704x576 - Norme de video digital : Interface multimédia haute définition (HDMI)
Entries video: - Type : Caméra video digital (couleur) - Résolution capture video digital : 1920 x 1080
networks: - Technologie de connectivity : Filaire - Protocole network : TCP/IP, NTP, DHCP, DNS - Caractéristiques : control flux, Power over Ethernet (PoE), support protocole LDAP, support network local (LAN) virtuel, support DiffServ, support of IPv6, Quality of Service (QDS), support SSH, support IPv4, Class of Service (CoS)
Interfaces: - 1 x network - Ethernet 10Based-T/100Based-TX (PoE) - RJ-45 - 1 x USB - 1 x audio / video - entries HDMI - HDMI de 19 broches de type A - 1 x video - 15 broches HD D-Sub (HD-15) - 1 x audio / video - output HDMI - HDMI de 19 broches de type A - 1 x microphone - entries - mini-phone 3,5 mm 4 pôles - 1 x audio - ligne de output - mini-phone stéréo 3,5 mm
Divers: - Protocole de signal digital : SIP - Protocole de compression de data : G.729, G.711, G.722, H.263, H.264, G.729AB, H.263+, G.722.1, H.350 - control de gain automatique, annulation d'écho - cables included : 1 x cables HDMI and 1 x cables network
Compliance standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x
Power supply: - device d'power supply : Power supply electrical - interne - voltage requise : CA 120/230 V (50/60 Hz) - Consommation en fonctionnement : 12 Watt
