Cisco Nexus 93180LC-EX - L3 - 24 Ports

Network equipment reference

Cisco Nexus 93180LC-EX - L3 - 24 Ports

Reference : Cisco Nexus 93180LC-EX

OPTINOC preserves this reference for technical research. The equipment is not offered for sale, and an optical-module association is displayed only when it is supported by an official manufacturer source reviewed by our team.

Request a module verification

Technical specifications

Product
Cisco Nexus 93180LC-EX - L3 - 24 Ports
Features
Layer 3 switching, haute availability, 4 fans replaceables hot, technologie Virtual PortChannel (vPC), In-Service Software Upgrade (ISSU), mode passerelle NPV, Virtual extensible LAN (VXLAN), Source-Specific Multicast (SSM), Ethernet Virtual Private Network (EVPN), memory tampon de system de 40 MB
performance
- Switching capacity : 3.6 Tbps - Virtual extensible LAN (VXLAN) - Sessions actives SPAN: 4
Capacity
- Instances Multiple Spanning Tree Protocol: 64 - Groupes HSRP: 490 - Par instances VLAN Rapid Spanning Tree: 4000 - Number of liens maximum in a canal de port: 32 - Maximum number of canaux de port: 512 - Chemins ECMP: 64 - Routing virtuel and instances de renvoi (VRF): 1000 - support de VLAN: 4096 - Entries ACL (output): 2000 - Entries ACL (entries): 4000 - Groupes d'espionnage IGMP: 8000 - Routes de multicast: 8000
RAM
24 GB
Disque Dur
64 GB SSD
Protocole de gestion à distance :
SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, SSH-2, CLI
Routing protocol
OSPF, RIP, RIP-2, BGP, EIGRP, HSRP, PIM-SM, MSDP, ECMP, MPLS
Ports
- 6 x 100Gbit/40Gbit LAN QSFP28 - 24 x 40Gbit/50Gbit LAN QSFP+ - 1 x management RJ-45 - 1 x management SFP+ - 1 x USB - 1 x serial (RS-232)
Standards compliance
IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 801.1p, IEEE 802.1ab (LLDP), IEEE 802.3ba
Included software
Cisco NX-OS
Expansion slots
0 (total) / 0 (free) x expansion Slots
Power supply
CA 120/230 V (50/60 Hz)
chassis type
Rack-mountable - 1U
