Cisco Nexus 92300YC - L3 - 66 Ports

Network equipment reference

Cisco Nexus 92300YC - L3 - 66 Ports

Reference : N9K-C92300YC

OPTINOC preserves this reference for technical research. The equipment is not offered for sale, and an optical-module association is displayed only when it is supported by an official manufacturer source reviewed by our team.

Request a module verification

Technical specifications

Product
Cisco Nexus 92300YC - L3 - 66 Ports
Features
Entries d'air de port, Equal-Cost Multipath (ECMP), spanning côté port, 4 fans, Virtual extensible LAN (VXLAN), tampon partagé 30 MB, Open Shortest Path First (OSPF), Ethernet Virtual Private Network (EVPN)
performance
- Switching capacity : 6 Tbps - Virtual extensible LAN (VXLAN)
Capacity
- Voies ECMP (Equal-Cost Multipathing) : 64
Protocole de gestion à distance :
SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, SSH-2, CLI
Routing protocol
RIP, RIP-2, IGMP, Multiprotocol BGP, MSDP, ECMP,MPLS
Ports
- 18 x 100 Gigabit QSFP28 - 48 x 10/25 Gigabit SFP+ - 1 x management RJ-45 - 1 x management SFP+ - 1 x USB - 1 x serial (RS-232)
Standards compliance
IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP)
RAM
16 GB
Disque dur
128 GB SSD
Included software
Cisco NX-OS
Expansion slots
0 (total) / 0 (free) x expansion Slots
Power supply
CA 120/230 V (50/60 Hz)
chassis type
Rack-mountable - 1.5U
