Cisco Nexus 92160YC-X - L3 - 48 Ports

Reference : Cisco Nexus 92160YC-X

OPTINOC preserves this reference for technical research. The equipment is not offered for sale, and an optical-module association is displayed only when it is supported by an official manufacturer source reviewed by our team.

Request a module verification

Technical specifications

Product: Cisco Nexus 92160YC-X - L3 - 48 Ports
Features: support network local (LAN) virtuel, IGMP snooping, support protocole Multiple Spanning Tree Protocol (MSTP), assistance accesss Control List (ACL), Per-VLAN Rapid Spanning Tree (PVRST), support protocole HSRP (Hot Standby Router Protocol), support VTEP (VXLAN tunnel endpoints), Virtual extensible LAN (VXLAN), Open Shortest Path First (OSPF), Source-Specific Multicast (SSM), Ethernet Virtual Private Network (EVPN)
performance: - Switching capacity : 3.84 Tbps - Virtual extensible LAN (VXLAN)
Capacity: - Entries (IPv4) de correspondance de prefixedd le plus long (LPM): 16000 - Entries (IPv6) de correspondance de prefixedd le plus long (LPM): 20000 - Routes IPv4 (multicast): 32000 - Interfaces virtuelles (VLAN): 4096 - Voies ECMP (Equal-Cost Multipathing): 64 - Instances Multiple Spanning Tree Protocol: 64 - Instances Rapid Per-VLAN Spanning Tree Plus: 507 - Entries VRF (Routing and transfert virtuel): 16000 - Entries d'observation IGMP: 32000 - Entries ACL (entries): 4000 - Entries ACL (output): 2000
Protocole de gestion à distance :: SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, SSH-2, CLI
Routing protocol: RIP, RIP-2, IGMP, Multiprotocol BGP, MSDP, ECMP
Ports: - 48 x 10GBased-T SFP+ - 6 x 40Gbit LAN QSFP+ - 4 x 100Gbit LAN QSFP+ - 1 x USB - 1 x management RJ-45 - 1 x management SFP+ - 1 x serial (RS-232) RJ-45
RAM: 16 GB
Flash memory: 20 MB
Standards compliance: IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP)
Included software: Cisco NX-OS
Expansion slots: 0 (total) / 0 (free) x expansion Slots
Power supply: CA 120/230 V (50/60 Hz)
chassis type: Rack-mountable - 1U
