Network equipment reference

Cisco ASA 5516-X avec FirePower Services

Reference : Cisco ASA 5516-X

OPTINOC preserves this reference for technical research. The equipment is not offered for sale, and an optical-module association is displayed only when it is supported by an official manufacturer source reviewed by our team.

Request a module verification

Technical specifications

Product: Cisco ASA 5516-X with FirePOWER Services
Features: firewall protection, support VPN, support network local (LAN) virtuel, haute availability
performance: - Inspection throughput: 1.8 Gbps - Multi-protocol firewall throughput: 900 Mbps - Connection rate: 15000 connections per second - Throughput control applications (AVC): 250 Mbps - Throughput control applications (AVC) et system de protection contre les intrusions (IPS): 125 Mbps - VPN throughput (3DES/AES): 250 Mbps - Throughput calibrage control applications (AVC) ou system de protection contre les intrusions (IPS): 150 Mbps
Capacity: - Concurrent sessions: 250000 - Cisco AnyConnect Premium/Apex VPN peers: 250 - certifiedd VPN IPSec: 300 - Interfaces virtuelles (VLAN): 100
Algorithme de chiffrement: Triple DES, AES
Protocole network / transport: transport IPSec
RAM: 8 GO
Flash memory: 8 GB
Disque Dur: 100 GB
Ports: - 8 x 1000Based-T - RJ-45 - 1 x 1000Based-T (management) - 1 x serial - RJ-45 - 2 x USB
Normes de conformité :: C-Tick, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, EN 55022 class A, CISPR 22, EMC, EN 60950-1, UL 60950-1 Second edition, FCC Part 15 B Class A, VCCI V-3, KC, IEC 60950-1 Second edition, CSA C22.2 No. 60950-1-07 Second edition
Logiciel provided: Pilotes de device & utilitaires
Power supply: CA 120/230 V (50/60 Hz)
Expansion slots: 1 (total) / 1 (free)
chassis type: Rack-mountable 1U
